  1. Concepts
  2. Resource relationships

VPC concepts

Written by
Yandex Cloud
Updated at November 9, 2026
View in Markdown

Yandex Virtual Private Cloud (VPC) is a service for creating cloud networks that are used for transmitting information within your cloud and connecting cloud resources to the internet.

Example of resources in a cloudA folder belongs to the cloud and contains two isolated cloud networks. In network 1, a web server virtual machine is connected to subnet A, 10.0.1.0/24, in availability zone A, and a MySQL cluster host is connected to subnet D, 10.0.2.0/24, in availability zone D. In network 2, a test virtual machine is connected to subnet A, 10.0.2.0/24, in availability zone A. Address ranges overlap only between different networks.CloudVirtual machineWeb serverVirtual machineTest environmentMySQL cluster hostDatabase

With VPC, you can:

  • Create subnets and connect cloud resources to them.
  • Enable information transfer between the cloud resources.
  • Connect the cloud resources to the internet.
  • Create static routes and manage traffic using security groups.
  • Route traffic to the internet via a NAT gateway.

The example above shows an allocation of Yandex Cloud resources across VPC networks. In the management console, you can open the infrastructure map, which shows the relationships between your resources in the selected folder in more detail.

Useful linksUseful links

  • Cloud networks and subnets
  • Cloud resource addresses
  • Static routing
  • Security groups
